EmStat4T Handheld electrochemical/impedance analyzer

PalmSens

The EmStat4T is a programmable handheld electrochemical/impedance analyzer with a touchscreen, ideal for sensor research and sensor-based applications. It offers two main operating modes:

Remote Control: Can be used as a traditional potentiostat, directly controlled via PSTrace software for Windows or the PSTouch app for Android. These apps can be used to perform measurements, view results, and analyze data.
Standalone Operation Mode: Controls the instrument via the touchscreen interface and executes wizard-guided electrochemical analysis applications. Custom applications can be easily written using the built-in Visual MethodSCRIPT editor in PSTrace for Windows. These applications can operate without a computer, tablet, or smartphone. Therefore, the EmStat4T is an ideal solution for real-time detection applications and field studies, such as environmental analysis or corrosion monitoring.

Main features

Visualized script editor

Build your EmStat4T application

The powerful MethodSCRIPT™ language lets you easily build your own applications and run them on EmStat4T. Write your applications using our visual MethodSCRIPT editor, which automatically generates MethodSCRIPT code for you.

Your measurement data has been securely stored.

Internal storage

The EmStat4T comes with 500 MB of built-in storage to store your measurements. All stored measurements can be easily viewed and transferred back to your PC using PSTrace software for Windows. Wherever you take your instrument, your data is always with you.

Manual Download

Specification

Specifications

General
dc-potential range	±3 V
compliance voltage	±5 V
maximum current	±30 mA
max. data acquisition rate	1M samples /s

Potentiostat
applied potential resolution	100 µV
applied potential accuracy	≤ 0.2% ±1 mV offset
current ranges	1 nA to 10 mA 8 ranges
measured current resolution	0.009% of CR (92 fA on 1 nA range)
measured current accuracy	< 0.2% of current ±20 pA ±0.2% of range
bandwidth settings	320 Hz, 3.2 kHz, 30 kHz or 570 kHz

Galvanostat
current ranges	10 nA, 1 uA, 100 uA, 10 mA 4 ranges
applied dc-current	±3 * CR (current range)
applied dc-current resolution	0.01% of CR
applied dc- current accuracy	<0.4% of current ±20 pA ±0.2% of range
potential ranges	50 mV, 100 mV, 200 mV, 500 mV, 1 V
measured dc-potential resolution	96 µV at ±3 V (1 V range) 48 µV at ±1.5 V (500 mV) 19.2 µV at ±0.6 V (200 mV) 9.6 µV at ±0.3 V (100 mV) 4.8 µV at ±0.150 V (50 mV)
measured dc-potential accuracy	≤ 0.2% ±1 mV offset
bandwidth settings	320 Hz, 3.2 kHz, 30 kHz or 570 kHz

FRA / EIS
frequency range	10 µHz to 200 kHz
ac-amplitude range	1 mV to 900 mV rms, or 2.5 V p-p

GEIS
frequency range	10 µHz to 100 kHz
ac-amplitude range	0.9 *CR

electrode connections	Two versions: Sensor cable: WE, RE, CE and ground ending in 2 mm banana plugs SPE connector: RE, WE and CE
housing	aluminum body only: 13 x 6.2 x 3.3 cm
weight	± 400 g
communication	USB-C or wireless
Battery	>8 hours with cell on <1 mA current 11.1 Wh capacity charging up to 80% takes approx. 2.5 hours a full charge takes approx. 3 hours Auto power off supported
internal storage space	500 MB, equivalent to > 15M datapoints or ~1000 measurement files
